5g Commercial CPE 5g Nr SA /Nsa LTE Tdd FDD 1g LAN Port 2.4GHz 5GHz Dual-Band Wi-Fi Ap CPE
|Performance||Non Line Speed Router|
|Operating System||Openwrt 19.07|
|Encryption Type||Wpa2-Psk, Wpa2, Wpa3|
|Specification||110 * 122 * 203mm|
|Production Capacity||50000 Piece/Pieces Per Month|
Product Description5G commercial CPE 5G NR SA /NSA LTE TDD FDD 1G LAN port 2.4GHz 5GHz dual-band Wi-Fi AP CPE
5G CPE is a wireless high-speed complete solution developed based on 5G cellular technology and Wi-Fi 6 home network technology.It uses a 64-bit quad-core CPU to provide dynamic data processing and management computing power for the reference design, a high-performance firewall-router, and high-performance virtual private network (VPN) security acceleration.
It can help broadband operators, Internet service providers (ISP) and OEMs to rapidly develop and deploy all-wireless home Internet for the latest 5G, by promoting plug-and-play gigabit connection solutions to replace DSL, cable and fiber deployment. Changes in the traditional home broadband industry.
1* Gigabit RJ45 WAN port.
1* Gigabit RJ45 LAN port .
1* RJ11,VOLTE voice. (Optional)
802.11ax 2T2R 2.4GHz
802.11ax 2T2R 5GHz
Temperature Range. -20°C ~ +60°C
Dimensions. 110 * 122 * 203mm
Power Supply. DC 12V/ 1.5AOperating system. Openwrt . 19.07
5G NR Sub-6GHz, Rel15 SA and NSA
|Band Selection 1||5G NR. n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n77/n78/n79LTE-FDD. B1/B3/B5/B7/B8/B18/B19/B20/B26/B28/B32LTE-TDD. B34/B38/B39/B40/B41/B42WCDMA. B1/B3/B5/B6/B8/B19DL 4*4 MIMO. B1/B3/B38/B40/B41/B42|
|Band Selection 2||5G NR. n2/n5/n7/n12/n25/n41/n48/n66/n71/n77/n78LTE-FDD. B2/B4/B5/B12/B13/B14/B25/B26/B29/B30/B41/B66/B71/B41LTE-TDD. B41/B48WCDMA. B2/B4/B5DL 4*4 MIMO. B2/B4/B25/B30/B41/B66|
|5G NR Sub-6GHz||- MIMO 4*4, 256QAM- Sub-6G SA 2.1Gbps/900Mbps (DL/UL)- Sub-6G NSA 2.5Gbps/650Mbps (DL/UL)|
|WIFI feature||WLAN: IEEE 802.11AX, WIFI 6WLAN: Built-in 2*2 MIMOWiFi : up to 1.7Gbps|
Basic featureNetwork manage , internet , SMS, phonebook etc.
Gospell Digital Technology was established in 2001, which is a leading manufacturer of advertising displays in China. Headquartered is in Chenzhou. Gospell also set up branches in many cities in China with over 1000 employees, include more than 100 well-experienced workers in its high-tech factories. Gospell has become the ODM / OEM partner of a number of world class companies, and have a high level research and development platform. Our team consists of over 20 CAD designers and structural engineers have strong ability to render your imagination into actual products. Our factory is under the ISO 9001 certification. Our products have been exported to over eighty (80) worldwide countries, Our products are certified as CCC, CE, FCC, RoHS,IP65,IP67 etc.. Welcome you esteemed partners to visit us and start business with you on the basis of mutual benefits . Thanks!Company and workshop
1.Do you provide customer's Logo and package design?
Yes, we can provide customized logo and design if order quantity reach 3000pcs.
2.Do you accept PCBA orders only?
Of course, we can provide PCBA in a short time with good quality.
3.Do you provide firmware support?
Sure , unlike other companies which are buying solutions from design company, we have our own firmware development team to support you in 100%.
4.How does your factory do regarding quality control?
We promise to use all new material to produce. Production is strictly monitored, and 100% QC inspection is done before shipment.
